Working Principle
Application
- Quarries & Aggregates – Efficient separation of crushed stone into multiple aggregate sizes for concrete, asphalt, or road base.
- Mining Sites – Pre‑screening of blasted ore to optimize subsequent crushing stages and improve overall plant throughput.
- Construction & Demolition Waste – Sorting brick, concrete, and mixed debris into reusable material fractions, aiding recycling efforts.
- Recycling Facilities – Handling reclaimed materials like concrete and asphalt, helping separate usable aggregates from fines.
- Infrastructure Projects – On‑site screening for base materials at road, rail, and dam construction areas—minimizing material transport and speeding up logistics.
SS‑7018 Mobile Inclined Screening Plant combines fast, modular screening technology with crawler mobility and on‑board power, making it ideal for large-scale mining, aggregate, and recycling sites. Its design supports high throughput (up to ~300 t/h), flexibility in screening levels, and operational independence—reducing setup time, transport logistics, and overall project costs..
Video Presentation
Product Parameter
| Project | Name | SS-7018 |
| Feeding equipment | Feeding capacity (t/h) | 320 |
| Hopper volume (m ³) | 5 | |
| Maximum feeding particle size (mm) | 100 | |
| Feeding height (mm) | 2700 | |
| vibrating screen | Vibration machine model | 7018 |
| Vibration screen size (mm) | 7000×1800 | |
| Processing capacity (t/h) | 300 | |
| Number of sieve layers (layers) | 3 | |
| Vibration screen power （kW） | 9.5×2 | |
| Main belt | Length x Width (mm) | 10800×1350 |
| Power （kW） | 5.5×2 | |
| Belt for finished materials | Length x Width (mm) | 7000×1350 |
| Unloading height (mm) | 2700 | |
| Power （kW） | 7.5 | |
| conveyor belt A | Length x Width (mm) | 7280×800 |
| Unloading height (mm) | 2900 | |
| Power （kW） | 5.5 | |
| conveyor belt B | Length x Width (mm) | 7280×800 |
| Power （kW） | 5.5 | |
| Unloading height (mm) | 2900 | |
| conveyor belt C | Length x Width (mm) | 5050×800 |
| Power （kW） | 5.5 | |
| Discharge height | 2800 | |
| Transition belt | Length x Width (mm) | 1750×770 |
| Power （kW） | 3 | |
| Complete machine | Track chassis model | LDZ55-3657 |
| Engine power （kW） | 90 | |
| Whole machine weight (t) | 32.5 | |
| Machine processing capacity (t/h) | 220-320 | |
| Total power （kW） | 57 | |
| Working dimensions (length, width, height/mm) | 14300×13000×5230 | |
| Transportation dimensions (length, width, height/mm) | 14800×3750×3950 |
More Details
- Single Power Version: Requires an external power supply when crushing stones, suitable for job sites with stable electricity.
- Dual Power Version: More versatile. When a stable power supply is not available, the machine can operate directly with diesel.
2. Engine
- Standard Configuration: Equipped with a branded engine meeting China National III emission standard.
- Optional Upgrades: Can be upgraded to China Stage IV, EPA Tier 4, or Euro V engines to comply with local environmental regulations.
3. Delivery Terms
| Item | Terms |
|---|---|
| Delivery Time | Approx. 20–25 working days after down payment |
| Warranty | 12 months |
| Spare Parts | A full set of wear parts will be provided with the machine, and long-term supply is guaranteed |
| Service & Support |
|
FAQ
Q1: How many different sizes can the SS-7018 produce?
A1: The SS-7018 mobile inclined screener typically features a 2-deck screen, allowing it to separate materials into 3 different sizes simultaneously. Custom configurations with 3 decks are also available upon request.
Q2: Can the screening plant handle wet and sticky materials?
A2: Yes. For materials with high moisture or clay content, we can equip the screen with self-cleaning devices such as rubber balls or mesh brushes to prevent blinding and ensure consistent screening efficiency.
Q3: What is the difference between an inclined screener and a horizontal screener?
A3: An inclined screener (like the SS-7018) is more compact and easier to transport, making it ideal for general aggregate production. A horizontal screener (like the SSP-6200) offers higher precision and is better suited for difficult materials or precise sand classification.
Q4: How is the mobile screen transported between sites?
A4: The SS-7018 is mounted on a tracked chassis and is self-propelled. It can travel at speeds up to 2 km/h under its own power. For long-distance transport on highways, it can be loaded onto a low-bed trailer.
