Working Principle
The SF-380D-2S Mobile Integrated Crushing and Screening Machine is an upgraded version of the SF-380D impact crusher. It features an enhanced screening module, enabling the simultaneous production of three different sizes of finished products. This machine integrates feeding, crushing, and screening functions into a single unit, offering a more efficient and cost-effective solution. The innovative design reduces the need for multiple machines, streamlines material flow, and cuts down on transportation and installation costs.
The SF-380D-2S offers greater flexibility and productivity. With a single machine, it serves as a complete mobile stone crushing production line. It is capable of simultaneously producing three different sizes of finished products, ensuring continuous and smooth operation.
Application
Key application areas include:
-
Construction Waste Recycling
Ideal for processing urban construction waste, this machine can transform discarded concrete, bricks, and other debris into reusable aggregates, supporting city recycling projects and adhering to environmental standards. -
Mining and Quarrying
The SF-380D-2S is designed to process medium-hard ores and rocks such as limestone and bluestone in mining and quarrying industries, providing high-quality aggregates for further processing and diverse applications. -
Road and Railway Construction
Perfect for infrastructure projects, including road and railway construction, the SF-380D-2S efficiently produces aggregates of varying sizes to meet the specific needs of construction projects, ensuring timely delivery and project success. -
Sand and Gravel Production Line
The SF-380D-2S is well-suited for sand and gravel production lines, with the ability to produce aggregates of various sizes according to market demand, enhancing both production efficiency and product quality. -
Coal and Metallurgy Industry
The SF-380D-2S is ideal for raw material crushing in the coal and metallurgy industries, capable of handling medium-hard materials to produce the required particle sizes for smelting and further processing. -
Environmental Protection and Resource Recycling
In the waste recycling industry, the SF-380D-2S processes a wide range of materials, helping reduce resource wastage and promoting eco-friendly processing.
Video Presentation
Product Parameter
| Project | Name | SF-380D-2S-DP |
| Feed section | Feeding capacity (t/h) | 230 |
| Hopper volume (m³) | 5 | |
| Power (kw) | 4.5×2 | |
| Feeder size (length x width) (mm) | 3960×1280 | |
| Feeding height (mm) | 3850 | |
| Crusher | Crusher model | 1214 |
| Feed inlet size (length x width) (mm) | 1380×970 | |
| Maximum feed particle size (mm) | 600 | |
| Adjustment range of discharge port (mm) | 300-500\0-150 | |
| Crusher weight (t) | 18 | |
| Crusher power (kw) | 220 | |
| Main belt | Length x Width (mm) | 11000×1600 |
| Unloading height (mm) | 3250 | |
| Power (kw) | 9.5×2 | |
| Belt for finished materials | Length x Width (mm) | 5000×1350 |
| Unloading height (mm) | 2660 | |
| Power (kw) | 7.2×2 | |
| Return material hanging sieve | Length x Width (mm) | 4600×2160 |
| Power (kw) | 3.7×2 | |
| Number of sieve layers (layers) | 3 | |
| Screen size (mm) | 4000×1540 | |
| Transition belt | Length x Width (mm) | 1750×770 |
| Power (kw) | 3 | |
| Side conveyor belt | Length x Width (mm) | 5150×800 |
| Power (kw) | 5.5×2个 | |
| Return conveyer belt | Length x Width (mm) | 7300×770 |
| Power (kw) | 5.5 | |
| De-ironing separator | Length x Width (mm) | 2100×910 |
| Power (kw) | 3 | |
| Complete machine | Track chassis model | LDZ55-3657 |
| Engine power (kw) | 400 | |
| Generator power (kw) | 400 | |
| Whole machine weight (t) | 55 | |
| Machine processing capacity (t/h) | 150-180 | |
| Total power of crushing work (kw) | 292.3 | |
| Working dimensions (length, width, height/mm) | 17450×10700×4000 | |
| Transportation dimensions (length, width, height/mm) | 17450×3500×4000 |
More Details
1. Single Power Version & Dual Power Version
SF-380D-2S Mobile Integrated Crushing and Screening Machine is available in two versions: Single Power and Dual Power.
- Single Power Version: Requires an external power supply when crushing stones, suitable for job sites with stable electricity.
- Dual Power Version: More versatile. When a stable power supply is not available, the machine can operate directly with diesel.
2. Engine
- Standard Configuration: Equipped with a branded engine meeting China National III emission standard.
- Optional Upgrades: Can be upgraded to China Stage IV, EPA Tier 4, or Euro V engines to comply with local environmental regulations.
3. Delivery Terms
| Item | Terms |
|---|---|
| Delivery Time | Approx. 20–25 working days after down payment |
| Warranty | 12 months |
| Spare Parts | A full set of wear parts will be provided with the machine, and long-term supply is guaranteed |
| Service & Support |
|
